Sound Deadening & Insulation

WS-0003
£0.00
In stock
1
Product Details

We supply and fit the Dodo range of sound deadening and insulation products.

One of the first and most important stages for any van conversion is taking that bare panel van and creating a warm and condensation free base. There are three main stages to achieve this - Sound Deadening, Thermo Acoustic Liner and Insulation.

In our Crux & Bespoke conversions we've been using the Dodo Mat range of products and have now created kits based on van sizes to make it easy for the self-build convertor. Whilst the subject of sound deadening and insulation has many theories and opinions, this is our recommended method (based on experience) and what we use in our builds.

Sound Deadening - Dodo Mat DEADN Hex Sheets

Supplied in small sheets with self-adhesive backing, the 1.8mm butyl backed foil sheets stick to any flat outer skin panel and reduce unwanted vibrations & structural noise. Approx. 60% coverage on flat panels, we also advise fully covering the wheel arches to reduce road noise. See more technical info from Dodo Mat below.

Thermo Acoustic Layer - Dodo Thermo Liner 6mm

Dodo Thermo Liner is a high grade foil lined XPE closed cell foam which is applied to all outer skin panels. Supplied on a roll and easily cut with a knife, it's a 6mm sound and heat insulation material for a quieter & warmer van and prevents condensation build up on the van's bodywork. See more technical info from Dodo Mat below.

Insulation - Dodo Thermo Fleece 50mm

Supplied in 390mm wide x 10m long rolls, Thermo Fleece by Dodo Mat is an itch-free sustainable insulation quilt manufactured from recycled plastic bottles. Simply tear off to the required length and fill into any voids. When fitting to the roof and flat sides, apply a small amount of heat resistant adhesive (eg. Trimfix) to hold in place. See more technical info from Dodo Mat below.

Optional - Flooring - Dodo Super Liner 6mm

There are many different methods for insulating under the floor (which is very important) and we've left this as optional. On our vans, we fit strips of the Dodo Super Liner on the lower section of the floor ribs. Our flooring panels (which also contain insulation) are then bonded directly to the top surface of the floor ribs. See more technical info from Dodo Mat below.

We also have the option to upgrade the Thermo Liner to Thermo Liner Pro in 6, 10 or 12mm thickness - please contact us if this is required.


As a guide on pricing

SWB Medium Sized Van (eg. VW Transporter) supplied and fitted - £859 (inc VAT)

LWB Large Sized Van (eg. VW Crafter) supplied and fitted - £1484 (inc VAT)


Please get in touch to book a slot at our workshop in Bordon, Hampshire.
